Sullair Certified Glider Program for Towable Air Compressors

EPA COMPLIANCE* MEETS SULLAIR RELIABILITY AND DURABILITY

The Sullair Certified** 375 Glider Series features a new John Deere replacement engine and remanufactured Sullair air end—Plus, all new components to finish out the package.

  • New John Deere Tier 3 replacement engine
  • New components
  • Legendary Sullair remanufactured air end

* State and regional regulations may apply
** To be deemed SULLAIR CERTIFIED, the glider must use Sullair OEM parts, fluids and filters. The final product must then pass rigorous testing, inspection and a final Quality Department verification.

0,00 $

Available on backorder

Category

Description

 FLOW

375 - 425 cfm
10.6 -12 m³/min

 PRESSURE

150 - 200 psi
10.3 - 14 bar

 POWER

140 hp
104 kW



Features & Benefits

  • New John Deere replacement engine
    • Two-year or 3000-year warranty
  • New components surrounding the engine and air end
  • Legendary Sullair remanufactured air end

Options

  • 375H
  • 375HHAF
  • 425H

Models & Specs

Performance

375H

  • Actual Delivery cfm (m³/min): 375 (10.6)
  • Rated Pressure psi (bar): 150 (10.3)
  • Pressure Range max/min psi (bar): 150(10.3)/80 (5.5)
  • Sound Level dBA: 76
  • Fuel Consumption 100% Load gph (l/h): ;6.55 (25)
  • Max Operating Altitude ft (m): 10,000 (3048)

375HHAF

  • Actual Delivery cfm (m³/min): 375 (10.6)
  • Rated Pressure psi (bar): 200 (14)
  • Pressure Range max/min psi (bar): 200(14)/80 (5.5)
  • Sound Level dBA: 76
  • Fuel Consumption 100% Load gph (l/h): 6.55 (25)
  • Max Operating Altitude ft (m): 10,000 (3048)

425H

  • Actual Delivery cfm (m³/min): 425 ;(12)
  • Rated Pressure psi (bar): 150 (10.3)
  • Pressure Range max/min psi (bar): 150(10.3)/80 (5.5)
  • Sound Level dBA: 76
  • Fuel Consumption 100% Load gph (l/h): 6.55 (25)
  • Max Operating Altitude ft (m): 10,000 (3048)

Engine

375H, 375HHAF, 425H

  • Make & Model: John Deere 4045HF285 (T3)
  • Cylinders: 4
  • Bore & Stroke in (mm): 4.19 x 5.00 (106 x 127)
  • Rated Power hp (kW): 140 (104
  • Rated Speed rpm: 2200
  • Cooling System Capacity gal (l): 4 (15)
  • Engine Oil Capacity qts (l): 9 (8.5)
  • Fuel Tank Capacity gal (l): 56(53)
  • Electrical System Voltage: 12
  • Battery Rating CCA: 1100

DPQ Package — Includes Running Gear

375H, 375HHAF, 425H

  • Working weight lbs (kg): 4440 (2014)
  • Dry weight lbs (kg): 4050 (1837)
  • Length in (mm): 156.2 (3967.5)
  • Width in (mm): 77.2 (1960)
  • Height in (mm): 74 (1880)
  • Max Towing Speed mph (km/h): 55 (89)
  • Axle Rating lbs (kg): 5000 (2268)
  • Tire Size: 225/75D15
