Model & Specs
General
Actual Delivery cfm (m³/min): 185 (5.2)
Rated Pressure psig (bar): 100 (7)
Pressure Range min/max (bar): 80/125 (5.5/8.6)
Engines
Make & Model: CAT C2.2 | KUBOTA KUB1803 | PERKINS 404F-E22T
Operating Speed rpm: 2720
Available Power bhp (kW): 49 (36.5)
Displacement in³ (l): 135 (2.13) | 111 (1.82) | 135 (2.13)
Cooling System Capacity gal (l): 2.6 (9.8) | 2.75 (10.4) | 2.6 (9.8)
Engine Oil Capacity qts (l): 7.6 (7.1) | 7.3 (6.9) | 7.6 (7.1)
Fuel Tank Capacity gal (l): 27 (102)
Electrical System Voltage: 12
Battery Rating CCA: 1000
Performance
Fuel Consumption at Full Load gph (l/h): 2.9 (10.9) | 2.7 (10.2) | 2.9 (10.9)
Maximum Operating Altitude ft (m): 9840 (3000) | 9000 (2743) | 9840 (3000)
Compressor
Service Valves No/Size in (mm): 2 / ¾ (19)
Compressor Oil Capacity gal (l): 2.1 (7.9)
DPQ Package — Includes Running Gear
Working weight lbs (kg): 2275 (1032) | 2175 (987) | 2275 (1032)
Dry weight lbs (kg): 2060 (934) | 1960 (889) | 2060 (934)
Length in (mm): 131 (3327)
Width in (mm): 59 (1499)
Height in (mm): 58 (1473)
Track Width in (mm): 51 (1295)
Axle Rating lbs (kg): 3700 (1678)
Tire Size: ST175/80D13
DLQ Package — Less Running Gear
Working weight lbs (kg): 2050 (930) | 1950 (845) | 2050 (930)
Dry weight lbs (kg): 1835 (833) | 1740 (789) | 1835 (833)
Length in (mm): 79 (2007)
Width in (mm): 41 (1041)
Height in (mm): 48 (1219)
FLOW
PRESSURE
POWER
