Description
FLOW
1600 cfm
PRESSURE
80 – 150 psi
POWER
540 hp
DOWNLOAD THE BROCHURE
DOWNLOAD ADDITIONAL DOCUMENTS
Features & Benefits Proven and Durable Package
Legendary Sullair 25-Series Air End
Highway towable running gear
Improved 1500-hour air-oil separator design with lower compressor lubricant requirements
Multiple lockable service doors with robust push to close latches
Upgraded paint for improved rust and corrosion resistance
Choice of Reliable Caterpillar C15, Cummins QSX15 or Perkins 2506J engines
Tier 4 Final compliant
1600 cfm at 100 to 150 psi
AWF® All Weather Fluid standard factory fill for compressor
Compact Design
20% smaller for easier maneuverability, storage and transit*
Nearly 2500 pounds lighter for easier tow and load*
Forklift pockets standard for ease of transport
Two-machine loadability on step-deck trailer
Improved Fuel Efficiency
Approximately 20% lower part load fuel consumption*
10% overall fuel consumption improvement*
Up to 10 hours of runtime from onboard fuel source
Easy-operation valve to connect to an external fuel source for extended duty runtime
Available With and Without Running Gear
7″ Sullair Touch Screen Controller (STS)
In-depth compressor and engine performance information on demand
Rugged touch screen works even when wearing gloves
User access passcode
Full color, digital display
Sullair AirLinx® — a Telematics Solution Providing:
GPS to keep track of your machines via Internet-connected devices
Fleet management
Remote monitoring and troubleshooting
*Compared to previous Sullair models
Options Options & Extras
Aftercooled and Afterfiltered
These models include next generation condensate management system—no condensate drain required
Afterfiltered air meets Class 1 specifications per ISO8573-1
Refinery package
Service Features & Options
Fast evac oil change
Maintenance kits available for service intervals from 50 – 2500 hours
Models & Specs Performance
Actual Delivery cfm (m³/min): 1600 (45.3)Rated Pressure psig (bar): 150 (10.3)Pressure Range, max/min psig (bar): 150 (10.3) / 80 (5.5)Service Valves, main/auxiliary: 1 (3″ NPT) / 2 (.75″ NPT)Compressor Fluid Capacity gal (l): 40 (151)Maximum Operating Altitude ft (m): 12,000 (3658)Fuel Consumption Full Load gal/h (l/h): 24 (90.8)Sound Level (U.S. EPA) dbA: 76Ambient Capability °F: -20 to 120
Engines
Available Makes & Models (Emissions Level): Caterpillar C15 Diesel & Perkins 2506J Diesel (T4F)Displacement in³ (l): 928 (15.2)Cylinders: 6Bore x Stroke in (mm): 5.4 (137) x 6.73 (171)Operating Speed rpm: 1800Minimum Idle Speed rpm: 1400Available Power bhp (kW): 540 (403)Fuel Tank Capacity gal (l): 249 (943)DEF Capacity gal (l): 12.8 (48.4)
Weights & Dimensions
DTQ – Includes Running Gear
Working weight lbs (kg): 19,085 (8657)Dry weight lbs (kg): 17,269 (7833)Length in (mm): 239 (6071)Width in (mm): 88 (2235)Height in (mm): 101 (2565)
DLQ – Less Running Gear
Working weight lbs (kg): 17,577 (7973)Dry weight lbs (kg): 15,761 (7149)Length in (mm): 208 (5283)Width in (mm): 88 (2235)Height in (mm): 89 (2261)
For Cummins unit specs, select “Download Additional Documents”.
